High Speed Print and Apply Labelers (HSL)

Request More Information ›

Ossid’s High Speed Print and Apply Labelers (HSL) are a complete stand-alone printing and labeling system. The HSL Series can apply pre-printed labels or print and apply labels to packaged products in a wide variety of industries with speeds of up to 175 packages per minute depending on application. With the ability to interface with customer’s ERP systems and storage of an unlimited number of SKU/product set-ups, this stand-alone print and apply labeling system is ideal for any size processor. Ossid’s HSL Series equipment is designed, manufactured, and built in the United States, making it flexible to changes in the North American market.

HSL Series Models:

  • HSL 100 – Top Only
  • HSL 200 – Bottom Only
  • HSL 300 – Top and Bottom Combo

Features & Benefits

  • Complete printing and labeling system with own transport conveyors
  • Simple user interface with a touch screen HMI
  • Unlimited number of SKU storage in HMI
  • Many interchangeable parts with Ossid WPL system
  • Speeds of 150 – 175 packages per minute depending on customer application
  • 2 applicator options available
  • Mechanical physical tamp applicator
  • Air blow on air jet applicator
  • Automatic horizontal and vertical adjustment on top labeler based on SKU setup

Technical Specifications

  • Length: 36” (914 mm)
  • Height: 36” (914 mm)
  • Width: 26” (660 mm)
  • Electrical: 120 VAC., 60 Hz, Isolated line 20 AMP, Single Phase
  • Air Requirements: Pressure Regulator and Filter 0.5 CFM @ 70-90 PSI
  • Max Package Length: 16”
  • Label Roll Requirements: Label Roll must have a 3" core, 12” diameter
  • Speed (based on printing quantity and label size): 150 – 175 packages/minute
  • 3” color user interface

Options

  • PC interface to connect to customer ERP system
